MB AM5 ASRock B650M-H/M.2+ je proizvod iz kategorije Matične ploče.
-
Superb Productivity- PCIe Gen5 (M.2)
-
Rock-Solid Durability- 6+1+1 Power Phase, 50A Dr.MOS for VCore
-
CPU- Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors*
-
Chipset- AMD B650
-
Memory- Dual Channel DDR5 Memory Technology
-
2 x DDR5 DIMM Slots- Supports DDR5 ECC/non-ECC, un-buffered memory up to 6400+(OC)*
Specifikacije
|
Superb Productivity
|
- PCIe Gen5 (M.2) |
|
Rock-Solid Durability
|
- 6+1+1 Power Phase, 50A Dr.MOS for VCore |
|
CPU
|
- Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors* |
|
Chipset
|
- AMD B650 |
|
Memory
|
- Dual Channel DDR5 Memory Technology |
|
2 x DDR5 DIMM Slots
|
- Supports DDR5 ECC/non-ECC, un-buffered memory up to 6400+(OC)* |
|
Max. capacity of system memory
|
128GB |
|
BIOS
|
- 256Mb AMI UEFI Legal BIOS with GUI support |
|
Graphics
|
Integrated AMD RDNA™ graphics (Actual support may vary by CPU) |
Audio
|
Audio
|
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
|
LAN
|
- Gigabit LAN 10/100/1000 Mb/s |
|
•Stavka
|
- Realtek RTL8111H |
|
CPU:
|
- 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode* |
|
Chipset:
|
- 2 x PCIe 4.0 x1 Slots (PCIE2 and PCIE3)* |
|
•Stavka
|
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module* |
|
•Stavka
|
- 15μ Gold Contact in VGA PCIe Slot (PCIE1) |
|
CPU:
|
- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode* |
|
•Stavka
|
- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* |
|
Chipset:
|
- 4 x SATA3 6.0 Gb/s Connectors |
|
RAID
|
- Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices |
|
•Stavka
|
- Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices* |
|
•Stavka
|
* Requires additional M.2 NVMe expansion cards to support RAID 10 |
|
USB
|
- 1 x USB 3.2 Gen1 Type-C (Rear) |
|
•Stavka
|
- 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front) |
|
•Stavka
|
- 6 x USB 2.0 (2 Rear, 4 Front) |
|
•Stavka
|
* All USB ports support ESD Protection |
|
1 x CPU Fan Connector (4-pin)*
|
- 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)** |
|
•Stavka
|
- 1 x 24 pin ATX Power Connector |
|
•Stavka
|
- 1 x 8 pin 12V Power Connector |
|
1 x Front Panel Audio Connector
|
- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) |
|
•Stavka
|
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) |
|
•Stavka
|
* CPU_FAN1 supports the fan power up to 1A (12W). |
|
•Stavka
|
** CHA_FAN1~3/WP support the fan power up to 2A (24W). |
|
•Stavka
|
CHA_FAN1~3/WP can auto detect if 3-pin or 4-pin fan is in use. |
|
1 x HDMI Port
|
- 1 x DisplayPort 1.4 |
|
•Stavka
|
- 1 x USB 3.2 Gen1 Type-C Port |
|
•Stavka
|
- 3 x USB 3.2 Gen1 Type-A Ports |
|
•Stavka
|
- 2 x USB 2.0 Ports |
|
•Stavka
|
- 1 x RJ-45 LAN Port |
|
1 x BIOS Flashback Button
|
- HD Audio Jacks: Line in / Front Speaker / Microphone |
|
Software
|
- ASRock Motherboard Utility (A-Tuning) |
|
ASRock Instant Flash
|
*These utilities can be downloaded from ASRock Live Update & APP Shop. |
|
2 x SATA Data Cables
|
- 3 x Screws for M.2 Sockets |
|
Form Factor
|
- Micro ATX Form Factor: 9.6-in x 8.9-in, 24.4 cm x 22.6 cm |
|
OS
|
- Microsoft Windows® 10 64-bit / 11 64-bit |
|
Certifications
|
- FCC, CE |
|
•Stavka
|
- ErP/EuP ready (ErP/EuP ready power supply is required) |
